2.4.2 Dimensions
2.4.3 Indicators
150mm
(5.9in)
100mm
(3.94in)
100mm
(3.94in)
145mm
(5.71)
610mm
(24in)
450mm
(17.7in)
Indicator Status Explanation
ON= The grid is abnormal and the system is in Back-up
mode.
BLINK = The grid is normal and the system is in On-grid
mode.
OFF = With no input source, the system is in waiting mode.
ON = The communication with the inverter is normal, and
the 12V power supply from the inverter is normal.
BLINK 1= The communication with the inverter is normal,
and the 12V power supply from the inverter is abnormal.
BLINK 2= The communication with the inverter is abnormal,
and the 12V power supply from the inverter is normal.
O = The communication with the inverter is abnormal, and
the 12V power supply from the inverter is abnormal.
On = Fault has occurred.
O = No fault.
