Goodwe GW10K-SDT-20 User Manual

63
User Manual V1.0-2022-01-17
10 Technical Parameters
Max. Output Current (A) 12.8 16.0 19.1 31.9
Max. Output Fault Current (peak
and duration) (A/ms)
38/5 38/5 89/5 89/5
Inrush Current(peak and
duration) (A/us)
30/50 30/50 30/50 50/50
Nominal Output Current (A) 11.6 14.5 17.4 28.9
Maximum output overcurrent
protection（A）
38.4 38.4 88.9 88.9
Output Power Factor ~1 (Adjustable from 0.8 leading to 0.8 lagging)
Max. Total Harmonic Distortion <3%
E󽗋ciency
Max. E󽗋ciency 98.3% 98.3% 98.4% 96.9%
European E󽗋ciency 97.6% 97.6% 97.8% 96.4%
CEC E󽗋ciency 97.8% 97.8% 98.0% /
Protection
DC Insulation Resistance
Detection
Integrated
Residual Current Monitoring Unit Integrated
DC Reverse Polarity Protection Integrated
Anti-islanding Protection Integrated
AC Overcurrent Protection Integrated
AC Short Circuit Protection Integrated
AC Overvoltage Protection Integrated
DC Switch Integrated
DC Surge Arrester Type II（Type III Optional）
AC Surge Arrester Type III（Type II Optional）
DC Arc Fault Circuit Interrupter Optional
Emergency Power O󽗈 Optional
Rapid Shutdown Optional
Remote Shutdown Optional
Active anti-islanding method Integrated (AFD)
General Data
Operating Temperature Range
(℃）
-30~60 (60 °C for outdoor unconditioned with solar e󽗈ects.)
Relative Humidity 0~100%
Max. Operating Altitude (m) ≤4000

Goodwe GW10K-SDT-20 Specifications

General

Brand	Goodwe
Model	GW10K-SDT-20
Category	Inverter
Language	English
