03 Product Introduction User Manual V1.0-2022-01-17
Name Description
PV Input Terminal Used to connect the PV module DC input cables.
DC Switch Start or stop DC input.
USB Port Reserved. USB Port is used for system upgrade and conó½—‰guration.
Ventilation valve -
Communication
Port
Used to connect communication modules like Bluetooth, WiFi, LAN, 4G,
etc.
Smart Meter +
RS485
Used to connect the Smart Meter or RS485 communication cable.
DRED(6Pin)
/ Remote
Shutdown (2pin)
Used to connect DRED or remote shutdown communication cable. DRED
for Australia and New Zealand, Remote Shutdown only for Europe.
AC Output
Terminal
Used to connect AC output cable. Connect the inverter and the utility grid.
Fans Used to cool the inverter. Without Fan: GW8KAU-DT, GW10KAU-DT.
LED Indicator Indicates working state of the inverter
LCD Optional. Used to check the parameters of the inverter.
Button
Optional. Used to control contents displayed on the
screen.
Grounding Point Used to connect the PE cable.
Mounting Plate Used to install the inverter.
