Goodwe GW10KT-DT Quick Installation Guide

01
01 Safety Precautions
• Theinformationinthisquickinstallationguideissubjecttochangeduetoproductupdates
orotherreasons.Thisguidecannotreplacetheproductlabelsorthesafetyprecautionsinthe
usermanualunlessotherwisespeci󽗉ed.Alldescriptionshereareforguidanceonly.
• Beforeinstallations,readthroughthequickinstallationguideandtheusermanualtolearn
abouttheproductandtheprecautions.
• Allinstallationsshouldbeperformedbyprofessionalandknowledgeabletechnicianswhoare
familiarwithlocalstandardsandsafetyregulations.
• Checkthedeliverablesforcorrectmodel,completecontents,andintactappearance.Contact
theafter-salesservicecenterifanydamageisfoundoranycomponentismissing.
• Useinsulatingtoolsandwearpersonalprotectiveequipmentwhenoperatingtheequipment
toensurepersonalsafety.Wearanti-staticgloves,clothes,andwriststripwhentouching
electrondevicestoprotecttheinverterfromdamage.
• Strictlyfollowtheinstallation,operation,andcon󽗉gurationinstructionsinthisguideanduser
manual.Themanufacturershallnotbeliableforequipmentdamageorpersonalinjuryifyou
donotfollowtheinstructions.Formorewarrantydetails,pleasevisithttp://www.goodwe.com.
General Disclaimer
DC Side
1. Ensurethecomponentframesandthebracketsystemaresecurelygrounded.
2. ConnecttheDCcablesusingthedeliveredDCconnectorsandterminals.Themanufacturer
shallnotbeliablefortheequipmentdamageifotherconnectorsorterminalsareused.
3. EnsuretheDCcablesareconnectedtightlyandsecurely.
4. MeasuretheDCcableusingthemultimetertoavoidreversepolarityconnection.Also,the
voltageshouldbeunderthepermissiblerange.
AC Side
1. Thevoltageandfrequencyattheconnectingpointshouldmeettheon-gridrequirements.
2. AnadditionalprotectivedevicelikethecircuitbreakerorfuseisrecommendedontheAC
side.Speci󽗉cationoftheprotectivedeviceshouldbeatleast1.25timestheACoutput
ratedcurrent.
3. PEcableoftheinvertermustbeconnected󽗉rmly.Theresistancebetweentheneutralwire
andtheearthcableislessthan10Ω.
4. YouarerecommendedtousecoppercablesasACoutputcables.Contactthe
manufacturerifyouwanttousealuminumcables.
Inverter Side
1. Terminalsatthebottomoftheinvertercannotbearmuchload.Otherwise,theterminals
willbedamaged.
2. Alllabelsandwarningmarksshouldbeclearaftertheinstallation.Donotscrawl,damage,
orcoveranylabelonthedevice.
3. Warninglabelsontheinverterareasfollows.
Safety Disclaimer
Warning

Goodwe GW10KT-DT Specifications

General

Brand	Goodwe
Model	GW10KT-DT
Category	Inverter
Language	English
