Goodwe GW9600A-ES - 2.3 Mounting Location Rules

Introduction
7
1. WiFi Reset Reload 2. LED Indicators 3. DC Switch
4. AC Bypass Switch 5. PV Input Terminal 6. Battery Terminal
7. Auto-transformer Terminal 8. On-Grid Terminal 9. Back-up Terminal
10. Grounding (PE) Busbar 11. Energy Meter CT Terminal 12. BMS
13. EMS 14. Grounding (PE) Busbar 15. WiFi Module
02 Product Introduction | Introducción al producto
Parts | Piezas
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
