19
05 Installation
User Manual V1.0-2023-03-20
Installation Space Requirements
• Horizontal installation
• Triangle installation
• Back-to-back installation
≥800mm
≥500mm
≥200mm
≥200mm
Do not place anything that will block the heat sink of the two inverters.
