What to do if my Goodwe Inverter shows Utility Loss?
If your Goodwe Inverter shows a 'Utility Loss' error, it means the grid is not connected. First, check the grid connection cables and make sure they are properly connected. Then, verify the grid's usability to ensure it is functioning correctly.
How to fix Over Temperature error on Goodwe Inverter?
If your Goodwe inverter is showing an 'Over Temperature' error, it means the internal temperature is higher than the normal specified value. To resolve this: * Reduce the ambient temperature around the inverter. * Move the inverter to a cooler location. If the issue persists, further assistance may be needed.
What to do if Goodwe Inverter shows Ground I Failure?
If your Goodwe Inverter displays a 'Ground I Failure', it indicates that the ground current is too high. Unplug the inputs from the PV generator and check the peripheral AC system. When the problem is cleared, reconnect the PV panel and check the inverter status.
How to troubleshoot Isolation Failure on a Goodwe GW3600S-UK?
To address an 'Isolation Failure' on your Goodwe Inverter, check the impedance between PV (+) & PV (-) and ensure the PV inverter is earthed. The impedance value must be greater than 2M?. If the problem persists, further assistance may be needed.
What causes PV Over Voltage on a Goodwe GW3600S-UK?
If your Goodwe Inverter is showing a 'PV Over Voltage' error, check whether the PV open voltage is higher or too close to the maximum input voltage. If the problem still exists when the PV voltage is less than the maximum input voltage, further assistance may be needed.
What to do if my Goodwe GW3600S-UK has Vac Failure?
If your Goodwe Inverter shows a 'Vac Failure', the PV Inverter will automatically restart within 5 minutes if the grid returns to normal. Also, make sure grid voltage conforms with the specification. If the problem still exists, further assistance may be needed.
What does Fac Failure mean on a Goodwe GW3600S-UK Inverter?
If your Goodwe Inverter displays a 'Fac Failure', the PV Inverter will automatically restart within 5 minutes if the grid returns to normal. Also, make sure grid frequency is in conformity with the specification. If the problem still exists, further assistance may be needed.
How to resolve Consistent Failure on a Goodwe GW3600S-UK?
If your Goodwe Inverter is experiencing a 'Consistent Failure', disconnect PV (+) or PV (-) from the input and restart the PV Inverter. If the problem still exists, further assistance may be needed.
What to do for Relay-Check Failure on Goodwe GW3600S-UK?
To address a 'Relay-Check Failure' on your Goodwe Inverter: 1. Disconnect all PV (+) or PV (-). 2. Wait for a few seconds. 3. After the LCD switches off, reconnect and check again. If the message appears again, further assistance may be needed.
Why does my Goodwe GW3600S-UK shut down with Insufficient sunlight?
When sunlight is insufficient, the Goodwe PV Inverter may continuously start up and shut down automatically due to insufficient power generated by the PV panel. If the problem remains, further assistance may be needed.
General| Model | GW3600S-UK |
|---|---|
| Rated Power | 3600 W |
| Rated AC Output Power | 3600 W |
| Max. AC Apparent Power | 3600 VA |
| Max. Output Current | 16 A |
| Rated Output Voltage | 230 V |
| Max. Efficiency | 97.6 % |
| MPPT Number | 2 |
| DC Input Number | 2 |
| Max. Input Current | 11 A |
| Number of MPP Trackers | 2 |
| Output Frequency | 50/60Hz |
| Cooling | Natural convection |
| Protection Degree | IP65 |
| Protection Class | Class I |
| Warranty | 5 years |
| AC Voltage Range | 180~280V |
| Operating Temperature | -25°C to 60°C |
Explanation of various symbols used throughout the manual for warnings and information.
Essential safety guidelines and precautions for operating and installing the inverter.
Instructions for correctly mounting the inverter for optimal performance.
Check for external damage and verify all included accessories upon receiving the inverter.
Detailed steps for installing the inverter unit, including position selection.
Guidelines for making AC and DC electrical connections to the inverter.
Guidance on diagnosing and resolving common issues and error messages.
Description of the inverter's front panel indicators and their meanings.
Explanation of the status indicated by the yellow, green, and red indicator lights.
Details on the inverter's LCD screen layout, display areas, and information shown.
List of error messages displayed by the inverter and their descriptions.
Procedure for resetting the inverter's wireless monitoring ID.
Specifications and performance data for various GoodWe inverter models.
List of certifications and approvals obtained by the inverter.
Details on the standard warranty duration for SS series products.
Requirements for keeping the warranty card and product nameplate visible.
Conditions under which the inverter will be maintained, repaired, or replaced.
Situations where the product warranty is considered invalid.
Contact information for customer service and technical support for GoodWe SS series inverters.
