Goodwe GW3600S-UK User Manual

10
3.4 Electrical Connection
Connections must be made in compliance with local
regulations and the requirements of local power
authorities/companies.
In accordance with VDE0126-1-1/A1, the inverter incorporates
a Residual Current Monitoring Unit (RCMU) which monitors
residual current from the solar module to the grid side of the
inverter. The inverter can automatically differentiate between
fault current and normal capacitive leakage currents.
3.4.1 Connection to grid (AC side Connection)
A Check the grid (utility) voltage and frequency at the
connection point of the inverter. It should be 230VAC (or
220VAC), 50/60Hz, and single phase.
B Disconnect the breaker or fuse between the PV-inverter
and the utility.
C Connect the inverter to the grid as follows:
` Switch off the AC breaker.
` Disassemble the female connector of the AC wire
connector and connect the AC wires to the connection
socket as indicated.
Figure 3.4.1-1
已发行

Goodwe GW3600S-UK Specifications

General

Model	GW3600S-UK
Rated Power	3600 W
Rated AC Output Power	3600 W
Max. AC Apparent Power	3600 VA
Max. Output Current	16 A
Rated Output Voltage	230 V
Max. Efficiency	97.6 %
MPPT Number	2
DC Input Number	2
Max. Input Current	11 A
Number of MPP Trackers	2
Output Frequency	50/60Hz
Cooling	Natural convection
Protection Degree	IP65
Protection Class	Class I
Warranty	5 years
AC Voltage Range	180~280V
Operating Temperature	-25°C to 60°C
