Installation Manual
Stationary Trailer Refrigeration Unit
Page
14
71.01.121 / 00
Copyright by GOVI GmbH 2013. The reproduction of this document or any part there of is prohibited! The right is reserved to make technical changes in the course of further development!
Table 4-1 Technical data
Table 4-2 List of material
Designation Material
Structure Sheet metal, ferrous material
Condenser, evaporator Aluminium, copper
Electrical components
Copper, PVC,
miscellaneous materials
Compressor
Ferrous materials, copper and other
materials
Coating Epoxide compound
Designation
arktik 2000US arktik 2500US arktik 1500US/F
Refrigerated trailer internal
temperature
T
A
=35,6°F [2°C]
T
A
=35,6°F [2°C] T
A
=0°F [-18°C]
Supply voltage 115 V / 1 ~ Phase 115 V / 1 ~ Phase 220 V / 1 ~ Phase
Frequency 60 Hz 60 Hz 60 Hz
Refrigeration capacity 6845 BTU/h [2000 W] 7240 BTU/h [2120 W] 4720 BTU/h [1380 W]
Power consumption 1428 W 1207 W 1817 W
Current consumption LRA 70 A 59 A 39 A
FLA 15 A 15 A 8 A
Defrost Automatic hot gas defrost Automatic hot gas defrost Automatic electrical
Evaporator air flow 650 cfm [1100m³/h] 560 cfm [950m³/h] 560 cfm [950m³/h]
Condenser air flow 650 cfm [1100m³/h] 650 cfm [1100m³/h] 650 cfm [1100m³/h]
Protection class, mounting
side
IP54
IP54 IP54
Refrigerant
(Chlorine:
zero – non ozone depleting)
R452A
R134a R452A
Refrigerant quantity 2,22 lbs [1,00kg] 1,33 lbs [0,6kg] 2,58 lbs [1,17kg]
Maximum operating
temperature
104°F [40°C]
104°F [40°C] 104°F [40°C]
Dimensions See Fig. 4-2 See Fig. 4-2 See Fig. 4-2
Weight 138 lbs [63kg] 122 lbs [55kg] 138 lbs [63kg]
Colour RAL9010 RAL9010 RAL9010
