GPI G8P - Specifications; Pump Specifications; Component Details

MAINTENANCE OPERATION
ASSEMBLY /
INSTALLATION
GETTING STARTED
6
EN
SAFETY /
SPECIFICATIONS
G8P PORTABLE FUEL TRANSFER PUMP
Housing Material Aluminum
Pump Rate Up to 8 GPM (30 LPM)
Duty Cycle 15minutesON,30minutesOFF
Suction LIft Up to 5.5 ft. (1.7m)
Operating
Temperature
-20°F to +125°F (-29°C to +52°C)
Operating Pressure 10 psi / 0.69 bar
Input 12-volt DC
Current Draw 15 amp
Motor 1100 RPM, 1/10 HP
Motor Approval UL listed to US and Canadian Standards
Cord (1) 12 ft. (3.6 m) Attached Power Cord
with Inline Switch and Alligator Clamps
Fuse 20 amp inline
Inlet 3/4in.NPT
Outlet 3/4in.NPT
Hose Type (1) Dispensing Hose, (1) Suction Hose
HoseSize (2) 8 ft. (2.0 m) x 5/8 in. (1.6 cm)
Nozzle 3/4 in. Manual, Unleaded
Weight 15.4 lbs (6.9 kg)
SPECIFICATIONS
Figure 2
Figure 1
ManualNozzle
Inlet Side
Outlet Side
Strainer
Ground Wire
5.32 in.
(13.51 cm)
3.32 in. (8.42 cm)
11.22 in. (28.50 cm)
