Grace ONE - Setting the Seat Angle

GRACE ONE 2013 Manual
57
Setting the seat angle
1.
In order to change the angle or the
horizontal position of the seat, loosen the
two Allen screws of the seat clamp, which
are located directly below
behind the seat.
2.
Loosen the two Allen screws of the seat
clamp, which are located directly below in
front of
the seat as well.
3.
Now you can slide the seat back and forth in
the clamp guide…
4.
5.
... and adjust the angle.
Finally,
tighten all four screws equally.
