GRACE ONE 2013 Manual
Torques
Torques for binding elements on the main frame
M5x12 swing arm screw
10 – 12 Nm
M12x30 strut mounting screw
25 – 30 Nm
M8x40 Dropout strut mounting screw
20 – 25 Nm
M8x16 Dropout fastening screw
20 – 25 Nm
Seat clamp
8 Nm
Torques of binding elements on the wheels
20 mm thru axle
30 – 35 Nm
M14 axle nut (rear)
50 – 55 Nm
Brake disks (manufacturer’s specifications from Magura)
4 Nm
Torques for handlebar and stem
Stem clamp (M8x25)
8 Nm
Handlebar clamp
6 Nm
Grip shift(manufacturer’s specifications from SRAM)
1,9 Nm
Throttle grip
1,9 Nm
Brake lever (manufacturer’s specifications from Magura)
4 Nm
Torques for add-on parts
Brake callipers (manufacturer’s specifications from Magura)
6 Nm
Post mount adapter
6 Nm
Rear derailleur fastening (manufacturer’s specifications from)
8 – 10 Nm
Gear cable fastener (manufacturer’s specifications from SRAM)
4 – 5 Nm
Bottom bracket (manufacturer’s specifications from SRAM)
48 – 54 Nm
