Replacement Parts
333394H 23
Parts List- Models 16Y385, 16Y386, 17A466
Ref.
If you have this
model sprayer
Order
Part
Number
Description
1 Kit, pump
16Y385, 17A466 17A217 Complete pump assembly includes 2, 3, 4, 5, 6, 7, 8
16Y385, 17A466 17A218 Pump housing includes 2, 3, 5
16Y386 17B415 Complete pump assembly includes 2, 3, 4, 5, 6, 7, 8
16Y386 17B416 Pump housing includes 2, 3, 5
2 All models 16Y425 O-ring
3 All models 16W849 Strainer
4 All models 17A219 Kit, needle assembly includes 5 and spray tip 17A222
5 All models 17A220 Kit, pump outlet
6 All models 17A402 Prime Pump/Spray valve
7 All models 17A221 Kit, Prime Pump/Spray knob includes qty. 1 of ref. 8
8 All models 119236 Screw, T-15 (torque 8-10 in-lb / 0.9-1.1 N
•m)
9 All models 17A223 Spray tips, (black/12-inch pattern, gray/4-inch pattern)
10 All models 16X880 Reciprocator assembly
12 Control, electronic includes motor, power cord and switch
16Y385 17A224 Single speed, 120 V (not shown)
16Y386, 17A466 17B653 Dual speed, 120 V
13a 16Y386, 17A466 16X868 Switch, dual speed control
13b 16Y385 16X869 Plug
14 All models 16W846 Support, 32 oz. cup
15 All models 17A226 Kit, 32oz., FlexLiner (3-pack)
16 All models 17B636 Cover, cup
17 All models 115719 O-ring
18 All models 16X806 VacuValve cap
19 16Y385, 17A466 17A227 Kit, enclosure blue includes qty. 13 of ref. 8,
16Y386 17A649 Kit, enclosure gray includes qty. 13 of ref. 8,
20 All models 16Y680 Label, USA
22 All models 16Y678 Label, control
23 All models 16Y636 Label, warning and model number, side (not shown)
24 Label, brand
16Y385 16Y677 TrueCoat 360
16Y386 17A473 TrueCoat 360 DSP
17A466 16Y679 TrueCoat 360 DS
25 All models 17A198 Label, warning, cord (not shown)
26 16Y386 17C468 Case, storage
All models 17F518 Kit, 42 oz. cup (not shown)
- - - 243104 Pump Armor, not shipped with sprayer 32 oz (not shown)
Replacement Danger and Warning labels, tags, and cards are available at no cost.
