Technical Specifications
3A4433B 37
Technical Specifications
HandHeld Sprayer
U.S. Metric
Max Working Pressure 2000 psi 14 MPa, 138bar
Maximum Amperage 3.6 Amps 3.6 Amps
Weight
4.6 lb 2.1 kg
Dimensions:
Length
14.0 in. 36.1 cm
Width
5 in. 12.7 cm
Height
10.5 in. 26.7 cm
Storage Temperature Range 32° to 113° F 0° to 45° C
Operating Temperature Range 40° to 90° F 4° to 32° C
Storage Humidity Range 0% to 95% relative humidity, non-condensing
Sound Power Level
88 dBa†
Power Cord 18 AWG, 3-wire
1.0 mm
2
, 3-wire
Length
18 in. 45.7 cm
Electrical Power Requirement 120 Vac, 60 Hz, 15A, 1 Ø
Maximum tip orifice
0.016 in. 0.41 mm
Pump damage will occur if fluid freezes in pump.
Damage to plastic parts may result if impact occurs in low temperature conditions.
Changes in paint viscosity at very low or very high temperatures can affect sprayer
performance.
† per EN60745-1/EN50580 measured at 3.3 feet (1m)
