Parts List
34 312805A
Parts List
2
7
7a
7b
66
64
7c
63
1
ti11633a
110
111
Ref Part Description Qty
1 258027 FRAME, stand 1
2 15R792 LEG, cart 2
4 117493 SCREW, mach, hex washer hd 10
7 289119 LEVER, handle, cam, includes 3, 5,
6, 7
4
7a PIN, pivot, handle, cart 4
7b SCREW, cap, socket head 4
7c NUT, lock, hex 4
63 120595 CLIP, tool 2
64 RIVET, blind, 1/8 x 1/4 in. 4
66 120151 RETAINER, caplug 4
110 15T783 ISOLATOR, foot 4
111 115723 SCREW, drill, hex washer 8
