20 307026
Technical Data
Category Data
Maximum fluid working pressure 360 psi (25 bar)
Air input pressure operating range 30-180 psi (2-12 bar)
Pump cycles per 1 gallon (3.8 liters) 40 (50 for Model 223954)
Maximum recommended pump speed for
continuous operation
100 cycles per min
Air consumption approx. 3 scfm (0.09 m#/min) at 1 gpm (3.8 liters/min) at 100 psi (7
bar) air pressure
Maximum Ambient temperature for T6
hazardous location use
120_F (50_C)
Maximum operating temperature of fluid
pump
480_F (248_C) for non–hazardous location applications only
Maximum operating temperature of air
motor
280_F (138_C) for non–hazardous location applications only
Wetted parts Stainless Steel, PTFE, Polyetheretherketone (PEEK)
