308479 23
Service
02640
Fig. 15
1
3
2
25
23
22
1
19
15
12
16
H
M
Insert bearings tapered end first.
Press-fit bearings flush with surface of center housing (1).
Apply medium-strength (blue) LoctiteR or equivalent.
Torque to 130–150 in-lb (15–17 N.m).
Detail of Air Valve Bearings
1
1
1
2
2
2
3
02639B
