Husky 1040 Aluminum and Stainless Steel Pumps, Series A
Your Model No. is marked on the pump’s serial plate. To determine the Model No. of your pump from the following
matrix, select the six digits which describe your pump, working from left to right. The first digit is always D,
designating Husky diaphragm pumps. The remaining five digits define the materials of construction. For example, a
pump with an aluminum air motor, aluminum fluid section, polypropylene seats, r balls, and r
diaphragms is Model
D 7 3 9 1 1. To order replacement parts, refer to the part lists on pages 26–28. The digits in
the matrix do not correspond to the ref. nos. in the parts drawing and lists.
Diaphragm
Pump Air Motor Fluid Section – Seats Balls Diaphragms
232501* aluminum aluminum – Hytrelr acetal Hytrelr
D (for all pumps) 7 Aluminum
(Standard)
1 (not used) – 1 (not used) 1 ( r) 1 ( r)
234124* 8 Aluminum
(Remote)
2 (not used) 2 (acetal) 2 (acetal) 2 (not used)
R sst (standard) 3 (aluminum) – 3 (316 sst) 3 (316 sst) 3 (not used)
S sst (remote) 4 (sst) – 4 (17–4 PH sst) 4 (440C sst) 4 (not used)
5 (not used) – 5 (Hytrelr) 5 (Hytrelr) 5 (Hytrelr)
C (aluminum
BSPT)
6 (Santoprener) 6 (Santoprener) 6 (Santoprener)
D (sst BSPT)
– 7 (buna–N) 7 (buna-N) 7 (buna-N)
– 8 (Vitonr) 8 (Vitonr) 8 (Vitonr)
– 9 (polypropylene) 9 (not used) 9 (not used)
– A (Kynarr) A (not used) A (not used)
– G (Geolastr) G (Geolastr) G (Geolastr)
* 232501, Aluminum 1040 Pump, Series A
Model No. 232501 is a private-label aluminum 1040 pump. Other than the label, it is the same
as Model No. D73525.
* 234124, Aluminum 1040 Pump, Series A
Model No. 234124 is a private-label aluminum 1040 pump. This pump is the same as Model No. D73GGG except
for the label and:
Reference #10 is 115666 Packing, U–cup, Viton
Reference #17 is 168518 O–ring, Viton
Use 243492 as the Air Valve Repair Kit
246450 Stainless Steel Air Motor Conversion Kit
Use kit 246450 and refer to manual 309643 (included in kit) to convert from aluminum air motor to stainless steel air
motor.
PTFE
PTFE
PTFE
PTFE
