Graco 234124 - Page 27

308479 27
Parts
Fluid Section Parts List (Matrix Column 3)
Digit
Ref.
No. Part No. Description Qty
3 101 188840 COVER, fluid; aluminum 2
102 188841 MANIFOLD, inlet;
aluminum
1
103 188842 MANIFOLD, outlet;
aluminum
1
104 188607 PLATE, air side; alum. 2
105 188607 PLATE, fluid side;
aluminum
2
106 115643 SCREW; M8 x 1.25;
25 mm (1 in.)
24
107 189044 BOLT; M12 x 1.75;
35 mm (1.38 in.); sst
2
108* 104319
O-RING; r
2
110
Y
188970 LABEL, warning 1
111 112182 MUFFLER 1
113 112183 PLUG: 1” npt; cst 4
114 None Not Used 0
Digit
Ref.
No. Part No. Description Qty
4 101 188860 COVER, fluid; sst 2
102 188862 MANIFOLD, inlet; sst 1
103 188861 MANIFOLD, outlet; sst 1
104 188607 PLATE, air side; alum. 2
105 188960 PLATE, fluid side; sst 2
106 112178 SCREW; M8 x 1.25;
25 mm (1 in.)
24
107 189044 BOLT; M12 x 1.75;
35 mm (1.38 in.); sst
2
108* 104319
O-RING; r
2
110
Y
188621 LABEL, warning 1
111 112182 MUFFLER 1
113 None Not Used 0
114 112257 NUT, hex; M8 x 1.25; sst 8
continued
PTFE
PTFE
