Graco 234124 - Page 29

308479 29
Parts
Fluid Section Parts List (Matrix Column 3)
(continued)
Digit
Ref.
No. Part No. Description Qty
C 101 188840 COVER, fluid; aluminum 2
102 192070 MANIFOLD, inlet;
aluminum; BSPT
1
103 192071 MANIFOLD, outlet;
aluminum; BSPT
1
104 188607 PLATE, air side;
aluminum
2
105 188607 PLATE, fluid side;
aluminum
2
106 115643 SCREW; M8 x 1.25;
25 mm (1 in.)
24
107 189044 BOLT; M12 x 1.75;
35 mm (1.38 in.); sst
2
108* 104319
O-RING; r
2
110
Y
188970 LABEL, warning 1
111 112182 MUFFLER 1
113 113991 PLUG: 1” BSPT; cst 4
114 None Not Used 0
D 101 188860 COVER, fluid; sst 2
102 192068 MANIFOLD, inlet; sst;
BSPT
1
103 192069 MANIFOLD, outlet; sst;
BSPT
1
104 188607 PLATE, air side;
aluminum
2
105 188960 PLATE, fluid side; sst 2
106 112178 SCREW; M8 x 1.25;
25 mm (1 in.)
24
107 189044 BOLT; M12 x 1.75;
35 mm (1.38 in.); sst
2
108* 104319
O-RING; r
2
110
Y
188621 LABEL, warning 1
111 112182 MUFFLER 1
113 None Not Used 0
114 112257 NUT, hex; M8 x 1.25; sst 8
Seat Parts List (Matrix Column 4)
Digit
Ref.
No. Part No. Description Qty
2 201* 188604 SEAT; acetal 4
202* 109205
O-RING; r
8
3 201* 188707 SEAT; 316 stainless steel 4
202* 109205 O-RING; R 8
4 201* 188708 SEAT; 17-4 stainless steel 4
202* 109205
O-RING; r
8
5 201* 188711
SEAT; Hytrelr
4
202 None Not Used 0
6 201* 191595 SEAT; Santoprene 4
202* 109205
O-RING; r
8
7 201* 15B275 SEAT; Buna–N 4
202* None Not used 0
8 201* 15B633 SEAT; Viton 4
202 None Not Used 0
9 201* 189722 SEAT; polypropylene 4
202* 109205
O-RING; r
8
A 201* 189723 SEAT; Kynar 4
202* 109205
O-RING; r
8
G 201* 194211 SEAT; Geolast 4
202* 109205
O-RING; r
8
