20 308546
Accessories
Must be purchased separately. Use only
genuine Graco parts and accessories.
Identification Labels 180698
Sheet of 14 sticky-back labels for labeling hose reels.
Includes labels for the following:
SAE 10–40 SAE 20W HYDRAULIC AIR
SAE 10–30 SAE 30W ANTI–FREEZE ATF
SAE 5–40 DEXRON CHASSIS
SAE 10W WATER GEAR
Reel Mounting Kit 237932
Secures mounting base to I-beam without the need for
drilling holes in the I-beam. Two brackets hold one
Series 700 hose reel. The mounting brackets fit all
standard I-beams with flanges up to 7 in. (178 mm).
Mount the brackets to the hose reel before securing
them to the I-beam.
05268
Adjustable clamp
Mounting bracket
I-beam
Roller Support Kit 237944
Positions the roller plate for overhead installations and
enables the hose to hang straight down through the
hose rollers.
05438
Roller plate and
hose rollers
(included with
hose reel)
Roller support arms
To Next Page
