Installation
307965W 3
Installation
These meters must be installed in-line as part of a dispense system as shown in Fig. The typical installation shown is
only a guide for selecting and installing an in-line meter. It is not an actual system design. Contact your Graco repre-
sentative for assistance in designing a system to suit your needs.
Key:
A In-line meter
B In-line strainer
C Shutoff valve
D Pressure relief valve
E Check valve
F Bleed-off valve
FIG. 1
A
B
C
KEY
A In-line meter
B In-line strainer
C Shutoff valve
D Pressure relief valve
E Check valve
F Bleed–off valve
D
E
F
