Accessories
307965W 9
Accessories
Strainer 223179
Install between the shutoff valve and the meter.
Removes particles from the lubricant. 40 mesh. 1/2 in.
npt (m x f)
Shutoff Valve 108458
Install upstream from the meter. Shuts off fluid supply
from the pump. 1/2-14 npt(f) both ends.
Technical Data
In-Line Electronic Lubricant Meter
US Metric
Maximum fluid working pressure 1500 psi 10.3 MPa, 103 bar
Flow Range* 0.12 to 12 gpm 0.456 to 45.6 lpm
Weight 1.9 lb 0.95 kg
Units of measurement
Factory-set in quarts. Display shows quantity in 0.01 incre-
ments up to 199.99 gallons, quarts, pints, or liters. Totalizes
in gallons or liters up to 19,999 units.
Inlet and outlet 1/2 npt, non-directional flow
Operating temperature range -4°F to 130°F -2°C to 55°C
Storage temperature range -40°F to 140°F -40°C to 60°C
Battery Specifications
Rated discharge current 100 microamps
Rated capacity 1.0 amp hour
Maximum continuous discharge current 1.0 milliamp
Wetted Parts Aluminum, carbon steel, nitrile rubber, nickel, bronze, stain-
less steel #304, cast ALNICO 8
