Technical Data
14 306518ZAE
Technical Data
.
5:1 Fire-Ball
®
300 Pumps
US Metric
Maximum fluid working pressure 900 psi 6.2 MPa, 62 bar
Fluid pressure ratio 5:1
Air pressure operating range* 40 to 180 psi 0.28 to 1.2 MPa, 2.8 to 12 bar
Maximum air consumption
13 ft
3
/minute for first gpm
pumped at 100 psi up to 8 addi-
tional ft
3
/min for each additional
gpm with pump operated within
recommended range
0.096 m
3
/minute for first lpm
pumped at 0.7 MPa, 7 bar up to
0.058 additional m
3
/min for each
additional lpm with pump oper-
ated within recommended range
Pump cycles per gallon (liters)
30
7.9
Recommended speed for optimum pump life
70 cycles per minute
Maximum recommended pump speed 130 cycles per minute 5 gpm 130 cycles per minute 19 lpm
Wetted Parts Steel, aluminum, buna-N, urethane
Sound pressure level (measured at 1 meter
from unit)
77.8 dB(A)
Sound power level (tested in accordance with
ISO 9614-2)
85.6 dB(A)
Approximate weight 17 lb 7.7 kg
Loctite
®
is a registered trademark of the Loctite Corporation.
