Parts
22 3A1334P
Air Valve Replacement Kit - 24H848 (npt),
24H849 (bspp), 24H850 (bspt) (FIG. 20)
Pilot Valve Replacement Kit - 24H749
This kit only includes the pilot valves (20). If you
also are repairing/replacing the air valve (38/40) and
air valve seal (23/16) order the Air Motor Service Kit
- 24J757 (npt), 24J758 (bspp) or 24J759 (bspt).
Air Motor Service Kit - 24J757 (npt), 24J758
(bspp), 24J759 (bspt) (F
IG. 21)
I
FIG. 20
Ref.
Description Qty.
Oil Grease
23 16 SEAL, air valve 1
38 40 VALVE, air, small 1
43 43 SCREW, M6 x 25 4
43
38/40
23/16
Ref. Description Qty.
20
VALVE, pilot
2
F
IG. 21
Ref.
Description Qty.
Oil Grease
20 20 VALVE, pilot
2
23 16 SEAL, air valve
1
40 40 VALVE, air, small
1
20
38/40
23/16
