Technical Data
30 3A1334P
Dimensions
600 mm
945 mm
1145 mm
23.6 in.
37.2 in.
45.0 in.
400 pound drum
120 pound drum
35 pound drum
14.5 in.
370 mm
28.1 in.
715 mm
36.0 in.
915 mm
a = 1/4 inch air inlet
b = 1/4 inch fluid outlet
c = 2 inch npt mounting configuration
d = ground screw
a
d
c
b
d
a
b
c
b
a
d
c
