Warnings
WARNING
ELECTRIC ELECTRIC
ELECTRIC
SHOCK SHOCK
SHOCK
HAZARD HAZARD
HAZARD
Thisequipmentmustbegrounded.Impropergrounding,setup,orusageofthesystemcan
causeelectricshock.
•Turnoffanddisconnectpoweratmainswitchbeforedisconnectinganycablesandbefore
servicingorinstallingequipment.
•Connectonlytogroundedpowersource.
•Allelectricalwiringmustbedonebyaquali󰘰edelectricianandcomplywithalllocalcodes
andregulations.
•Donotexposetorain.Storeindoors.
INTRINSIC INTRINSIC
INTRINSIC
SAFETY SAFETY
SAFETY
Intrinsicallysafeequipmentthatisinstalledimproperlyorconnectedtonon-intrinsicallysafe
equipmentwillcreateahazardousconditionandcancause󰘰re,explosion,orelectricshock.
Followlocalregulationsandthefollowingsafetyrequirements.
•InstallationshouldbeinaccordancewithANSI/ISARP12.06.01“InstallationofIntrinsically
SafeSystemsforHazardous(Classi󰘰ed)Locations”andtheNationalElectricalCode®
(ANSI/NFPA70).
•InstallationinCanadashouldbeinaccordancewiththeCanadianElectricalCode,CSA
C22.1,Part1,AppendixF.
•ForATEX,installperEN60079–14andapplicablelocalandnationalcodes.
•Equipmentthatcomesincontactwithintrinsicallysafeterminalsmustmeettheentity
parameterrequirementsspeci󰘰edinControlDrawing16M169.SeeAppendixAinManual
332013.Thisincludessafetybarriers,DCvoltagemeters,ohmmeters,cables,and
connections.Removetheunitfromthehazardousareawhenservicing.
•Ifaprinter,computer,orotherelectricalcomponentisconnected,itmustbeusedin
conjunctionwithasafetybarrier.
•Withoutthesafetybarrier,theequipmentisnolongerintrinsicallysafeandmustnotbe
operatedinhazardouslocations,asde󰘰nedinarticle500oftheNationalElectricalCode
(USA)oryourlocalelectricalcode.
•Donotinstallequipmentapprovedonlyfornon-hazardouslocationinahazardousarea.See
theIDlabelfortheintrinsicsafetyratingforyourmodel.
•Donotuseintrinsicallysafeequipmentwithapowersupplythathasnobarrier.Intrinsic
safetymaybecompromised.
•Groundthepowersupply.Avoltagelimitingsafetybarriermustbeproperlygroundedtobe
effective.Forpropergrounding,usea12gaugeminimumgroundwire.Thebarrier’sground
mustbewithin1ohmoftrueearthground.
•Donotremoveanycoveruntilpowerhasbeenremoved.
•Donotsubstitutesystemcomponentsasthismayimpairintrinsicsafety.
332013E5
