Operation
334567E 19
Operation
Spray Tip Installation
1. Perform Pressure Relief
Procedure, page 12.
2. Use spray tip (A) to insert
OneSeal
™
(B) into tip guard (C).
2. Insert Spray Tip.
3. Screw assembly onto gun. Tighten.
Spray
1. Spray test pattern. Adjust pressure to
eliminate heavy edges.
ti24653a
C
B
A
ti24664a
ti24652a
ti24669a
