Bead Dispenser Kit
3A5205A 5
Gun Orientation for 8 - 12 in.
Stripe Operation
NOTE: To avoid glass beads clumping, do NOT store
beads in hopper when not in use. Make sure to run
beads out of system when done.
For 8 - 10 in. stripe, adjust line width, loosen
set screws at (A) and loosen gun adjuster
(B). Tilt guns in for desired line width and
tighten. Keep bead dispensers together and
parallel to the ground.
8 - 10 in. stripe
ti6591a
