Graco ARGOS 80 User Manual

39
13.0 Adjusting Head Support/Harness Straps
When using with built-in harness always
use one of the bottom 4 height positions.
BEFORE adjusting the head support height,
have your child lean forward slightly.
Squeeze the red adjustment handle
 on
top of seat and pull head support up until it
snaps into one of the bottom 4 height
positions
.
To lower, squeeze red adjustment handle
and push down.
CHECK to make sure it is securely snapped
into one of the bottom 4 height positions by
pulling up on head support.
The harness straps must be even with or
just above the shoulders as shown by dotted
line
.




Graco ARGOS 80 Specifications

General

Type	Convertible Car Seat
Weight Limit (Rear-Facing)	5-40 lbs
Weight Limit (Forward-Facing)	22-80 lbs
Height Limit (Forward-Facing)	Up to 52 inches
Installation Method	LATCH or seat belt
Harness Type	5-point harness
Recline Positions	3
Warranty	1 year
Safety Features	Side impact protection, EPS energy absorbing foam
