Installation
3A6932B 5
Installation
Pressure Relief Procedure
To relieve pressure in the system, use two wrenches
working in opposite directions on the pump outlet fitting
to slowly loosen the fitting only until no more lubricant or
air is leaking from the fitting (F
IG. 1).
Auto-Fill Shut Off Installation
1. Disconnect power to the system (FIG. 2).
2. Relieve pressure in the system following the
Pressure Relief Procedure, see page 5.
This equipment stays pressurized until pressure is
manually relieved. To help prevent serious injury from
pressurized fluid, such as skin injection, splashing
fluid and moving parts, follow the Pressure Relief
Procedure when you stop dispensing and before
cleaning, checking, or servicing the equipment.
FIG. 1
FIG. 2
