Repair
10 334654B
4. Assemble leather throat packings
soaked earlier.
5. Loosely install packing nut with o-ring
onto cylinder.
6. Install o-rings inside cylinder and on
sleeve. Slide sleeve into bottom of
cylinder. Replace o-ring if necessary.
7. Apply liberal amounts of grease or oil to
piston packings.
8. Grease top inch or two of piston rod that
will go through the cylinder throat
packings. Gently guide displacement
rod up through throat packings. Tap
bottom of piston valve as necessary with
a leather or plastic hammer.
