Digital Tracking System (DTS)
18 311017A
Digital Tracking System (DTS)
Operation - Main Menu
Short press moves to next dis-
play.
Long press changes units or
resets data.
1 Start engine, pg 10.
Sprayer Model displays briefly.
e.g. L5900 = LineLazer 5900
Pressure display appears.
Dashes appear when pressure
is less than 200 psi (14 bar, 1.4
MPa).
2 Short press DTS button to
move to Speed (miles per
hour or kilometers per
hour).
3 Short press DTS button to
move to rolling average
Film Build (mils or
microns).
Note: Displays the average
wet film build over the last 20 ft
(6 m) sprayed. The proper line
width (LW) must be selected,
step 7.
WLD
25
WLD
WLD
WLD
