BASIC ELECTRICAL TERMINOLOGY
In any discussion of electricity, there are three basic terms you will need to understand.
CURRENT
VOLTAGE
RESISTANCE
CURRENT:
Current is the movement of the electrical charge.
Current Flows through the wires from the power source to the load.
Current is measured in AMPERES (AMPS, A or I). See Figure 1.
NOTE: Meter is only clamped around one wire.
VOLTAGE:
Voltage is the force that causes current to fl ow in a circuit.
Voltage is measured in VOLTS (V or E). See Figure 2.
FIGURE 1
FIGURE 2
ON/OFF
Switch
Ref
58
Power
Plug
Red (+)
White
Black
Green
Black (–)
Black
from Motor
ON/OFF
Switch
Ref
58
Power
Plug
Potentiometer
Ref 37
Red
(+)
White
Black
Green
Black (–)
Black
120 AC
V
Motor
To Next Page
