Graco fire-ball 425 - Parts List

Parts
308655K 17
Parts List
Model 205626, Series K
Wall-Mount Universal Pump
Includes items 1 to 113
Model 222065, Series C
55-Gallon Drum Cover-Mount Pump
Includes items 1 to 113, 150, and 151
Model 222095, Series C
55-Gallon Drum Bung-Mount Pump
Includes items 1 to 113, 150, 152, and 153
* Parts included in Repair Kit 238751 (purchase
separately).
▲ Replacement safety labels, tags, and cards are
available at no cost.
Ref
No.
Part
No.
Description
Qty.
1 AIR MOTOR (items 2 to 36)
1
2* 110247 SEAL, polyurethane, nitrile
1
3 101578 SCREW, cap, hex hd
8
5 102656 MUFFLER, air exhaust
1
7 116343 SCREW, ground
1
11 156698 PACKING, o-ring
1
12 158359 ACTUATOR, air valve
1
13 158360 YOKE, trip pod
1
15 158362 PIN, toggle
2
16 158364 PIN, pivot
2
17* 158367 GROMMET, lower valve
2
18 158377 PACKING, ring seal
1
19* 158378 PACKING, o-ring
1
20* 158379 PACKING, o-ring
1
21* 160261 NUT, valve
4
22* 160618 WIRE, lock
2
23 160623 ARM, toggle
2
24 190929 RING, lift
1
25 167585 SPRING, helical compression
2
26* 170709 POPPET, exhaust valve
2
27 207391 PISTON (items 27a to 27c, also
includes 207385 repair kit when
ordered as a replacement part
1
27a 102975 SCREW, rd hd mach;
6 - 32 x 1/4 in.
2
27b 158361 CLIP, spring
2
27c BARE PISTON (not sold
separately)
1
28 191544 BASE, air motor
1
29 191545 Rod, displacement
1
30 15E954 CYLINDER, air motor
1
31 207150 ROD, trip
1
32* 236079 POPPET, inlet valve
2
33 119344 LABEL, designation
1
35▲ 290259 LABEL, warning
1
36 191546 BEARING, throat
1
103 100279 BALL, sst
1
104 101190 BALL, sst
1
105* 156633 PACKING, o-ring
1
107* 113564 SEAL, u-cup
1
108* 156641 PACKING, o-ring
1
109 191547 PISTON/VALVE SEAT
1
110 191548 CYLINDER, fluid
1
111 183009 VALVE HOUSING
1
112 157182 RETAINER, ball
1
113 191123 RETAINER, seal
1
150 110127 SPACER, foot
1
151 191128 TUBE, ext.; 21.75 in. (553 mm)
1
152 191130 TUBE, ext.; 26.0 in. (661 mm)
1
153 222308 BUNG ADPATER
1
Ref
No.
Part
No.
Description
Qty.
