Technical Specifications
20 308655K
Technical Specifications
10:1 Fire-Ball 425 Pump
US Metric
Maximum working pressure 1800 psi 12.4 MPa, 124 bar
Fluid pressure ratio 10:1
Air operating range
40 to 180 psi 0.28 MPa to 1.24 MPa,
2.76 bar to 12.4 bar
Air consumption at 100 psi (0.7 MPa, 7 bar)
13 ft
3
/min per gallon pumped 6 m
3
/hour per liter pumped
Pump cycles 20 per gallon 5.3 per liter
Maximum recommended continuous pump
speed
60 cycles/min.; 3 gpm (11.4 l/min.)
Recommended speed for optimum pump life 15 to 25 cycles per min.
Sound data 78.0 dBa sound power at 100 psi air, 40 cycles per min.
Piston seals polyurethane with nitrile spreader
Rod seals polyurethane with nitrile spreader
Wetted Parts aluminum, steel, polyurethane, nitrile
Approximate weight (Model 205626, Universal
Pump)
28.7 lb 13.0 kg
All trademarks or registered trademarks are the property of their respective owners.
