Graco GMax ll 5900 - Page 16

Startup
16 310892B
Premium Operation
Main Menu
Close cover when spraying to
protect display
1 Do startup steps 1. - 3. 2 Start engine, page 11.
Sprayer Model momen-
tarily displays, e. g.,
G5900 = GMax 5900
Pressure display appears.
Dashes appear when pres-
sure is less than 200 psi (14
bar, 1.4 MPa).
Note: Information other than
pressure can not be accessed if
system pressure is greater than
200 psi (14 bar, 1.4 MPa) or if
the pump switch is ON.
WLD
60$57&21752/
3$,17
)/86+
WLD
WLD
/&&
WLD
WLD
