Graco IPH-25 Series User Manual

Related Manuals
2
Contents
Related Manuals . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
Models . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
Warnings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Isocyanate Hazard . . . . . . . . . . . . . . . . . . . . . . . . . 5
Material Self-ignition . . . . . . . . . . . . . . . . . . . . . . . 5
Moisture Sensitivity of Isocyanates . . . . . . . . . . . . 5
Keep Components A and B Separate . . . . . . . . . . 5
Foam Resins with 245 fa Blowing Agents . . . . . . . 5
Changing Materials . . . . . . . . . . . . . . . . . . . . . . . . . 5
Component Identification . . . . . . . . . . . . . . . . . . . . 6
Conversion Kit Installation . . . . . . . . . . . . . . . . . . 12
Setup . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
Operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27
Pressure Relief Procedure . . . . . . . . . . . . . . . . . . 29
Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . 31
Parts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32
Technical Data . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34
Performance Charts . . . . . . . . . . . . . . . . . . . . . . . 35
Graco Standard Warranty . . . . . . . . . . . . . . . . . . . 36
Graco Information . . . . . . . . . . . . . . . . . . . . . . . . . 36
Related Manuals
These manuals can be found at www.graco.com.
Models
IPH-25 SERIES
IPH-40 SERIES
CONVERSION KIT
* Full load amps with all devices operating at maximum capabilities. Fuse requirements at various flow rates and mix
chamber sizes may be less.
◆ Maximum flow rate given for 60 Hz operation. For 50 Hz operation, maximum flow rate is 5/6 of 60 Hz maximum
flow.
Reactor Hydraulic Proportioner
Part Description
312062
Reactor Hydraulic Proportioner, Operation
Manual
312063
Reactor Hydraulic Proportioner,
Repair-Parts Manual
Reactor Electric Diagrams
Part Description
312064
Reactor Hydraulic Proportioner, Electrical
Diagrams
AR Pour Gun
Part Description
312888 AR Pour Gun, Operation-Parts Manual
Proportioning Pump
312068 Proportioning Pump Repair-Parts Manual
Part,
Series
Full Load
Peak Amps*
Per Phase
Voltage
(phase)
System
Watts
Primary
Heater
Watts
Max Flow
Rate◆
lb/min
(kg/min)
Approximate
Output per
Cycle (A+B)
gal. (liter)
Hydraulic
Pressure
Ratio
Maximum Fluid
Working
Pressure
psi (MPa, bar)
255814, B 69 230V (1) 15960 8000 22 (10) 0.063 (0.24) 1.91:1 2000 (13.8, 138)
255815, B 46 230V (3) 15960 8000 22 (10) 0.063 (0.24) 1.91:1 2000 (13.8, 138)
255816, B 35 400V (3) 15960 8000 22 (10) 0.063 (0.24) 1.91:1 2000 (13.8, 138)
Part,
Series
Full Load
Peak Amps*
Per Phase
Voltage
(phase)
System
Watts
Primary
Heater
Watts
Max Flow
Rate◆
lb/min
(kg/min)
Approximate
Output per
Cycle (A+B)
gal. (liter)
Hydraulic
Pressure
Ratio
Maximum Fluid
Working
Pressure
psi (MPa, bar)
255811, B 100 230V (1) 23100 12000 50 (23) 0.076 (0.29) 1.64:1 2000 (13.8, 138)
255812, B 71 230V (3) 26600 15300 50 (23) 0.076 (0.29) 1.64:1 2000 (13.8, 138)
255813, B 41 400V (3) 26600 15300 50 (23) 0.076 (0.29) 1.64:1 2000 (13.8, 138)
Part, Series Description
24A024, A Conversion kit for existing H-25 and H-40 hydraulic proportioners
