Graco IPH-25 Series User Manual

Technical Data
34
Technical Data
All other brand names or marks are used for identification purposes and are trademarks of their respective owners.
Category Data
Maximum Fluid Working Pressure Models IPH-25 and IPH-40: 2000 psi (13.8 MPa, 138 bar)
Fluid:Oil Pressure Ratio Model IPH-25: 1.91:1
Model IPH-40: 1.64:1
Fluid Inlets Component A (ISO): 1/2 npt(f), 250 psi (1.75 MPa, 17.5 bar) maximum
Component B (RES): 3/4 npt(f), 250 psi (1.75 MPa, 17.5 bar) maximum
Fluid Outlets Component A (ISO): #8 JIC (3/4-16 unf), with #5 JIC adapter
Component B (RES): #10 JIC (7/8-14 unf), with #6 JIC adapter
Fluid Circulation Ports 1/4 npsm(m), with plastic tubing, 250 psi (1.75 MPa, 17.5 bar) maximum
Maximum Fluid Temperature 190°F (88°C)
Maximum Output (10 weight oil at
ambient temperature)
Model IPH-25: 22 lb/min (10 kg/min) (60 Hz)
Model IPH-40: 50 lb/min (23 kg/min) (60 Hz)
Output per Cycle (A and B) Model IPH-25: 0.063 gal. (0.23 liter)
Model IPH-40: 0.076 gal. (0.29 liter)
Line Voltage Requirement 230V 1 phase and 230V 3 phase units: 195-264 Vac, 50/60 Hz
400V 3 phase units: 338-457 Vac, 50/60 Hz
Amperage Requirement See Models, page 2.
Heater Power
(A and B heaters total, no hose)
See Models, page 2.
Hydraulic reservoir capacity 3.5 gal. (13.6 liters)
Recommended hydraulic fluid Citgo A/W Hydraulic Oil, ISO Grade 46
Sound power, per ISO 9614-2 90.2 dB(A)
Sound pressure, 1 m from equipment 82.6 dB(A)
Weight All IPH-25 Models: 535 lb (243 kg)
IPH-40 Models with 12.0 kW Heaters: 597 lb (271 kg)
IPH-40 Models with 15.3 kW Heaters: 597 lb (271 kg)
Wetted Parts Aluminum, stainless steel, zinc-plated carbon steel, brass, carbide, chrome,
fluoroelastomer, PTFE, ultra-high molecular weight polyethylene, chemically
resistant o-rings

Graco IPH-25 Series Specifications

General

Brand	Graco
Model	IPH-25 Series
Category	Controller
Language	English
