Component Identification
6
Component Identification
IPH System
Key:
A Hydraulic Proportioner
B Shot Controller, HMI, and Bracket
C Electrical Enclosure
D Linear Sensor Assembly
FIG. 1: IPH System with Front Cover Removed
A
B
C
D
ti11820a
Model 255811 shown
