Graco LineLazer IV Series User Manual

311066C 3
1 Align guns 2 Position guns: up/down,
forward/reverse, left right
3 Connect gun cables to left
or right, or both, selector
plates
a One gun: Disconnect one
gun selector plate from trig-
ger.
b Both guns simultaneously:
Adjust both gun selector
plates to the same position.
c Solid-skip and skip-solid:
Adjust solid-line gun to
position 1 and skip-line gun
to position 2.
ti6664a
ti6549a
1
2
ti3330a
ti3331a
ti3332a
ti3342a
a
b
c
