Technical Data
313036N 53
MAGNUM (257080)
ProLTS 19 (Series A)
MAGNUM (24N808)
ProLTS 19 (Series A)
Working pressure range 0-3000 psi
(0-21 MPa, 0-207 bar)
0-3000 psi
(0-21 MPa, 0-207 bar)
Electric motor
9.4A (open frame,
permanent magnet DC)
9.4A (open frame,
permanent magnet DC)
Operating horsepower 7/8 7/8
Maximum delivery (with tip) 0.38 gpm (1.44 lpm) 0.38 gpm (1.44 lpm)
Paint hose 1/4 in. x 50 ft
(6.4 mm x 15 m)
1/4 in. x 50 ft
(6.4 mm x 15 m)
Maximum tip hole size
0.019 in. (0.48 mm) 0.019 in. (0.48 mm)
Weight, sprayer only 43 lb (20 kg) 33 lb (15 kg)
Weight, sprayer, hose & gun 46 lb (21 kg) 36 lb (16 kg)
Dimensions (Upright):
Length 23.75 in. (60.32 cm) 21.25 in. (54 cm)
Width 19.25 in. (48.89 cm) 15.25 in. (39 cm)
Height 36.5 in. (92.71 cm) 36.75 in. (93 cm)
Dimensions (Folded Handle):
Length 23.25 in. (59.05 cm) 21.25 in. (54 cm)
Width 19.25 in. (48.89 cm) 15.25 in. (39 cm)
Height 22.00 in. (55.88 cm) 30 in. (76 cm)
Power cord 16 AWG, 3-wire, 6 ft (1.8 m)
Fluid inlet fitting 3/4 in. internal thread (standard garden hose thread)
Fluid outlet fitting 1/4 NPSM external thread
Inlet screen (on suction tube) 35 mesh (450 micron)
Wetted parts, pump & hose stainless steel, brass, leather, ultra-high molecular weight
polyethylene (UHMWPE), carbide, nylon, aluminum, PVC,
polypropylene, fluroelastomer
Wetted parts, gun aluminum, brass, carbide, nylon, plated steel, stainless steel,
UHMWPE, zinc
Generator requirement 1500 Watt minimum
Electrical power requirement 120 Vac, 60 Hz, 15A, 1 phase
Storage temperature range -30° to 160°F (-35° to 71°C)
Operating temperature range 40° to 115°F (4° to 46°C)
