Operation

Project Painter Plus

- For portable spray applications of architectural paints and coatings -

(Specifications, page 3.)

Use water-based or mineral spirit-type materials only.

Do not use materials having flash points lower than

100° F (38° C). This includes, but is not limited to, ace-

tone, xylene, toluene, or naptha. For more information

about your material, request MSDS from distributor or

retailer.

EN

Project Painter Plus

Model 16W119

ti22056a

IMPORTANT SAFETY INSTRUCTIONS

Read all warnings and instructions in this manual

and on the sprayer cord. Save these instructions.

See page 3 for model series information including

dispense rate, recommended hose length, guns, and

maximum working pressure.

Other manuals for Graco MAGNUM PROJECT PAINTER PLUS

Quick Guide4 pages

Questions and Answers:

M
Michael MartinAug 17, 2025
How to prime Graco MAGNUM PROJECT PAINTER PLUS Paint Sprayer?
- S
  Sandra RoachAug 17, 2025
  To prime your Graco Paint Sprayer, first, ensure the Prime/Spray Valve is in the PRIME position. Check that the inlet screen is free from clogs and the suction tube is fully immersed in the fluid. If these steps don't work, remove the suction tube from the paint and prime the pump using water or a solvent-based flushing fluid. If the inlet valve check ball is stuck, remove the suction tube and use a pencil to dislodge it, or try Power Flushing the sprayer. Also, check for and tighten any leaks in the suction tube connection. If the fluids you're using are viscous, try momentarily turning the Power Switch off and on to slow the pump.
H
Heather TateAug 19, 2025
What to do if my Graco MAGNUM PROJECT PAINTER PLUS Paint Sprayer pump cycles but doesn't build pressure?
- M
  Mary ColeAug 20, 2025
  If your Graco Paint Sprayer pump cycles but doesn't build pressure, start by priming the pump. Make sure that the inlet screen is clean and the suction tube is fully immersed in the paint. Check the suction tube for any leaks and tighten the connection if necessary. If you find cracks or damage, replace the suction tube.
D
Diana AliAug 23, 2025
Why does my Graco MAGNUM PROJECT PAINTER PLUS Paint Sprayer only dribble or spurt paint when triggered?
- A
  Anthony ArnoldAug 23, 2025
  If your Graco Paint Sprayer only dribbles or spurts paint when triggered, first, increase the pressure by slowly turning the Pressure Control Knob clockwise. If that doesn't work, unclog the spray tip. Also, check and clean the spray gun fluid filter. If the spray tip is too large or worn, replace it.
M
Ms. Sharon Hernandez MDAug 26, 2025
What to do if Graco Paint Sprayer motor does not run?
- E
  Elizabeth PerkinsAug 26, 2025
  If your Graco Paint Sprayer motor doesn't run, even when the power switch is on and the sprayer is plugged in, start by turning the pressure control knob clockwise to increase the pressure setting. Check if the electric outlet is providing power by trying a different outlet or testing the outlet with a working device. Reset the building circuit breaker or replace the fuse if necessary. Inspect the sprayer power cord for any damage and replace it if damaged. If paint or water is frozen in the pump, unplug the sprayer and place it in a warm area to thaw completely before attempting to start it.
M
Madison ProctorAug 28, 2025
Why did my Graco Paint Sprayer stop spraying?
- L
  Luis LindseyAug 28, 2025
  If your Graco Paint Sprayer suddenly stopped spraying, check the suction tube connection and tighten it if it's loose. Inspect the suction tube for cracks or vacuum leaks. Also, unclog the spray tip.
A
Arthur AlexanderAug 31, 2025
Why is paint leaking down the outside of my Graco MAGNUM PROJECT PAINTER PLUS Paint Sprayer pump?
- J
  Jamie MccoyAug 31, 2025
  If paint is leaking down the outside of your Graco Paint Sprayer pump, the pump packings are likely worn and need to be replaced.
S
Stephanie ThomasSep 2, 2025
Why Graco MAGNUM PROJECT PAINTER PLUS cannot achieve a good spray pattern even at maximum pressure?
- J
  Jonathan KentSep 2, 2025
  If your Graco Paint Sprayer can't achieve a good spray pattern even at maximum pressure, check that the reversible spray tip is in the SPRAY position. If the spray tip is too large for your sprayer, select a smaller one. Also, make sure the inlet screen is clean, and the material you're using isn't too thick; if it is, thin it out. If you're using an extension hose, try removing it.
L
leon86Sep 5, 2025
Why is my Graco MAGNUM PROJECT PAINTER PLUS motor hot and running intermittently?
- G
  glennlawsonSep 5, 2025
  If your Graco Paint Sprayer motor is hot and running intermittently, ensure that the vent holes in the enclosure are not blocked by obstructions or overspray, and make sure the sprayer is open to air. If you're using an extension cord, it might be too long or not heavy enough gauge, so replace it. Check that you are not using an unregulated electrical generator with excessive voltage. The sprayer requires 220-240 VAC, 50/60 Hz.
T
tfletcherSep 8, 2025
Why when I spray paint with Graco MAGNUM PROJECT PAINTER PLUS it runs down the wall?
- J
  Jack ScottSep 8, 2025
  If paint runs down the wall or sags when sprayed with your Graco Paint Sprayer, move the gun faster. Try using a tip with a smaller hole size or a tip with a wider fan. Also, make sure the gun is far enough from the surface.
B
brandy84Sep 12, 2025
What to do if Graco MAGNUM PROJECT PAINTER PLUS coverage is inadequate?
- P
  Paul DavisSep 12, 2025
  If the coverage is inadequate when spraying with your Graco Paint Sprayer, try moving the gun slower. Consider using a tip with a larger hole size or a tip with a narrower fan. Also, ensure that the gun is close enough to the surface.

Graco MAGNUM PROJECT PAINTER PLUS Specifications

General

Type	Airless Paint Sprayer
Maximum Pressure	2800 PSI
Flow Rate	0.24 GPM
Weight	15 lbs
Power Source	Electric
Maximum Flow Rate	0.24 GPM
Voltage	120V
Maximum Tip Size	0.015 in
Hose Length	25 ft
Spray Tip Size	0.015 in

Summary

Operation

Important Safety Instructions

Key safety warnings and instructions for operating the sprayer.

Trigger Lock

Pressure Relief Procedure

Steps to safely relieve pressure before cleaning or servicing the sprayer.

Specifications

Warnings

Grounding and Electric Requirements

Setup

Prime and Flush Storage Fluid

Steps to prime the sprayer and flush out storage fluid before first use or project start.

Install Tip and Guard on Gun

Instructions for correctly installing the spray tip and guard onto the spray gun.

Spraying Techniques

Unclogging Spray Tip

Procedure for clearing obstructions from the spray tip to resume spraying.

Tip Selection

Choosing the Correct Tip

Shutdown and Cleaning

Pail Flushing

Power Flush

Cleaning Gun Filter

Storage

Short Term Storage

Long Term Storage

Instructions for preparing and storing the sprayer for extended periods, including Pump Armor.

Troubleshooting
