Graco MAGNUM PROJECT PAINTER PLUS User Manual

Technical Data
30 332643B
Technical Data
Project Painter Plus
Working pressure range 0-207 BAR, 0-21 Mpa (0-3000 psi)
Electric Motor 4.5A
(open frame, universal)
Operating horsepower 3/8
Maximum delivery (with tip) .91 lpm (.24 gpm)
Paint hose 6.4mm X 7.5 m (1/4 in. x 25 ft)
Maximum tip hole size 0.015 in (0.38 mm)
Weight, Sprayer only 4.5 kg (10.0 lb)
Weight, Sprayer, Hose, & Gun 6 kg (13.2 lb)
Dimensions (Upright):
Length 35.2 cm (13.8 in)
Width 30.7 cm (17.1 in)
Height 35.1 cm (13.8 in)
Dimensions (Folded):
Length N/A
Width N/A
Height N/A
Power cord 1.0 mm², 3-wire, 1.8 m (6 ft)
Fluid inlet fitting 1/4 npsm external thread
Fluid outlet fitting 3/4 in. internally threaded (standard garden hose)
Inlet screen (on suction tube) 1190 micron (16 mesh)
Wetted parts, pump and hose stainless steel, zinc plated carbon steel, brass, ultra-high molecular weight
polyethylene (UHMWPE), Carbide, Nylon, Aluminum, PVC, polypropylene,
fluroelastomer
Wetted parts, gun aluminum, brass, carbide, nylon, ultra-high molecular weight polyethylene
(UHMWPE), zinc
Generator requirement 1500 Watt minimum
Electrical power requirement 220-240V AC 50/60 Hz, I phase, 10A
Storage temperature range◆❖ -35° to 71° C (-30° to 160° F)
Operating temperature range✔ 4° to 46° C (40° to 115° F)
◆ When pump is stored with non-freezing fluid. Pump damage will occur if water or latex paint freezes in pump.
❖ Damage to plastic parts may result if impact occurs in low temperature conditions.
✔ Changes in paint viscosity at very low or very high temperatures can affect sprayer performance.

Graco MAGNUM PROJECT PAINTER PLUS Specifications

General

Type	Airless Paint Sprayer
Maximum Pressure	2800 PSI
Flow Rate	0.24 GPM
Weight	15 lbs
Power Source	Electric
Maximum Flow Rate	0.24 GPM
Voltage	120V
Maximum Tip Size	0.015 in
Hose Length	25 ft
Spray Tip Size	0.015 in
