Graco Magnum X5 User Manual

Storage
26 332689D
5. When storage fluid comes out of prime tube (5-10
seconds) turn power switch OFF.
6. Move Prime/Spray valve to SPRAY to keep storage
fluid in sprayer during storage.
Stowing Sprayer
1. Screw inlet screen onto suction tube.
2. Coil hose. Leave it connected to sprayer. Wrap
hose around hose wrap bracket or sprayer stand.
3. Secure a plastic bag around suction tube to catch
any drips.
4. Store sprayer indoors.
ti2018a
ti9345a
NOTICE
• Before storing sprayer make sure all water is
drained out of sprayer and hoses.
• Do not allow water to freeze in sprayer or hose.
• Do not store sprayer under pressure.
ti9433a
ti12947a
ti22184a
ti5552a

Graco Magnum X5 Specifications

General

Type	Airless Paint Sprayer
Maximum Flow Rate	0.27 gallons per minute
Maximum Tip Size	0.015 inch
Maximum Operating Pressure	3000 PSI
Power Source	Electric
Voltage	120V
Maximum Hose Length	75 ft
Pressure Control	Adjustable
Recommended Annual Use	125 gallons per year
Motor	0.5 HP
