Motor Replacement
3A2333B 29
Motor Replacement
Removal
1. Perform Pressure Relief Procedure; page 9. Wait
5 minutes before servicing.
2. Remove pump (91); see Displacement Pump
Replacement, page 31.
3. Remove drive housing (90); see Drive Housing
Replacement, page 27.
4. Disconnect all three motor connectors from motor.
5. Remove motor wires from baffle 278075 and
remove baffle.
6. Remove two screws (23) and nuts (19) on side
opposite control.
7. Loosen two nuts (19) on side near control and
remove motor (84) from cart frame.
Installation
1. Slide new motor (84) under two screws (23) in cart
frame near control.
2. Install two screws (23) and nuts (19) on motor side
opposite control.
3. Tighten all four screws (23) and nuts (19). torque
nuts to 200 - 230 in-lb (25.6 - 29.0 N•m).
4. Install baffle.
5. Connect all three motor connectors to motor and
route through baffle.
6. Install drive housing (90); see Drive Housing
Replacement, page 27.
7. Install pump (91); see Displacement Pump
Replacement, page 31.
NOTICE
Do not drop gear cluster when removing drive hous-
ing or damage could occur. Gear cluster could stay
engaged in motor front end bell or drive housing.
