Component Identi
fication
3A0157A
7
Component Identification
11.
12.
10.
13.
1.
2.
4.
5.
6.
7.
8.
9.
3.
ti14839a
1
Premium Digital Display
2
ON/OFF s
witch
3
W
atchDog
™
Switch (not a
vailab
le on Mark V)
4
Pressure
Control
5
Prime /
Spra
y V
alve
6
Filter
7
Siphon T
ub
e
8P
u
m
p
9
Bearing Housing / ProConne
ct
™
10
Drain T
ube
11
T
rigge
r Lock
12
Model/serial tag
13
Hose Reel
6
8
