Parts
3A3442B 13
Air Motor Parts
Part No. 25A641, 2.5 in. (63.5 mm)
Replacement Danger and Warning labels, tags, and cards are available at no cost.
Ref. 25A641 Description Qty
201 24G695 KIT, cover, bottom; includes 202 (qty 1), 203,
207, 213 (qty 1), and 217
1
202 Not sold separately. See page 14. O-RING, cover 2
203 Not sold separately. See page 14. BEARING 1
204 Not sold separately. See page 14. O-RING, piston 1
205 15M289 CYLINDER, motor 1
206 15M302 COVER, cylinder (includes English warning
label)
1
207 Not sold separately. See page 14. SEAL, u-cup 2
208 Not sold separately. See Manifold Assembly (220, this
table), see page 14.
GASKET, manifold 2
209 Not sold separately. Manifold Assembly (220, this
table), see page 14.
GASKET, air valve 1
210 24H004 KIT, cover, top; includes 202 and 213 (qty 1 of
each). 15X353 also includes 230 and 231.
1
211 Not sold separately. See Manifold Assembly (220, this
table), see page 14.
SCREW, M6 x 25 8
212 15M314 BOLT, tie, hex head 2
213 24A366 VALVE, pilot (pack of 2) 1
214 24A351 VALVE, air; includes items 209 and 211 (qty 4) 1
215 15M213 MUFFLER 1
217 Not sold separately. See page 14. RING, retaining 1
218 Not sold separately. See page 14. ROD, air motor 1
219 25A657 KIT, piston, motor; includes16G561 adhesive. 1
220 24A579 MANIFOLD, assembly, includes 208, 209, and
211 (qty. 4)
1
229 15W719 (not shown) LABEL, warning (French and
Spanish)
1
230
O-RING, top plug (24G694 only) 0
231
PLUG, top cover (24G694 only) 0
