Parts
38
34
56
37
60
1
59
54
55
86
56
8
70
13
14
71
9
65
49
50
48
53
7
89
6
5
52
4
4a
40
47
45
46
44
64
42
43
66
35
3
63
67
2
16
19
27
18
41
39
61
62
37
36
33
17
92
97
95
40
57
58
98
99
75
Lubricate the threads. T
orque to 40–45 in–lb
(54–60 N.m).
T
orque to 130–140 in–lb (15–16 N.m).
Apply PTFE
tape to the top and bottom threads.
See Detail A, page 23.
T
orque to 70–90 in–lb (8–10 N.m).
The tube must drop freely in the pipe (1).
Apply sealant to the threads.
The seal in the bearing must face down.
Apply thread sealant to the motor tie bolts.
See Detail B, on page 23.
83
Model
223–635, Series C, with a hose and a gun.
