Repair
309574L 47
F
IG. 19. Transformer Continuity Tests
Part No. 15B352 Transformer (Models E-30 and E-XP2) shown
TI3470b
C2
R
TI4335A
806
817A
P
P1
T1
T2
T3
32
Detail B: Circuit Breaker Module and Hose Heat Wire Harness
P2
P3
P4
P5
P6
J13 on Temperature
Control Board
To J1 Connector, pins 5 and 6
P
C1
